Belt Conveyor

Product Introduction

Belt conveyor has the character of strong transport capacity, The conveyor belt can be used for horizontal or inclined transport, long transport distance, simple and easy to maintain, easy to implement automated operation. According to the requirements of the conveyor process, it can be a single conveyor, also several components or combined with other transport equipment to form a horizontal or inclined transport system to fit the different layout of the production line. It is widely used in metallurgy, cement, coal, chemicals, building materials, food, ports, and other fields.

Applied materials

Mining Iron, Beneficiation Of Magnetite, Pyrrhotite, Hematite, Limonite, Siderite, Etc.

Feturers

• Stable running, low noise, and long service life.
• Thread rod type take-up (tensioner) can be fitted at the tail to meet various conveying requirements.
• Flexible for multi-point feeding and discharging.
• Equipped with an alarming device for material blockage.
• Devices for speed loss and chain breakage protection are optional.

Technical Parameter

Model	Conveyor Belt			Delivery Length (mm)	Electric Drum Diameter (mm)	Capacity (t/h)	Power (kw)
	Width (mm)	Speed (m/s)	inclination (°)
TB-500	500	0.8~2.5	0~20	20~240	500、630	40~230	1.5~30
TB-650	650	0.8~2.5	0~20	20~240	500、630	67~391	1.5~45
TB-800	800	0.8~3.15	0~20	20~240	500、630	118~824	2.2~75
TB-1000	1000	1~3.15	0~20	20~240	500、630、800	230~1233	4~110
TB-1200	1200	1~3.15	0~20	20~240	500、630、800	300~1600	5.5~130
TB-1400	1400	1~3.15	0~20	20~240	630、800、1000	400~2000	7.5~160
TB-1600	1600	1~3.15	0~20	20~240	630、800、1000	500~2300	11~220
